# Multilayer printing for flexible and stretchable material

NOVA is a system for printing flexible, stretchable, and conformable electronics. Plan, NOVA’s newest software feature, unlocks advanced electronics printing capabilities, such as multilayer printing and print job editing.

## Get more information

Connect with our technical specialists to discuss your projects and get printing tips for flexible, stretchable, and conformable electronics.

![voltera-nova](https://info.voltera.io/hs-fs/hubfs/voltera-nova.png?width=300&height=31&name=voltera-nova.png "voltera-nova")

# Unlock multilayer printing on NOVA

NOVA is a system for printing flexible, stretchable, and conformable electronics. Plan, NOVA’s newest software feature, unlocks advanced electronics printing capabilities, such as multilayer printing and print job editing.

![Multilayer icon](https://info.voltera.io/hs-fs/hubfs/NOVA%20multilayer_black.png?width=76&height=80&name=NOVA%20multilayer_black.png "Multilayer icon")

#### Unlock multilayer

Easily generate a height map that adapts to height changes in each layer.

![Edit artwork\_nova dark](https://info.voltera.io/hs-fs/hubfs/Edit%20artwork_nova%20dark.png?width=80&height=80&name=Edit%20artwork_nova%20dark.png "Edit artwork_nova dark")

#### Customize print jobs

Adjust the print order of layers, delete unwanted features, and save print jobs with the same settings.

![Material profiles icon](https://info.voltera.io/hs-fs/hubfs/2023_Materials_bl-3.png?width=80&height=80&name=2023_Materials_bl-3.png "Material profiles icon")

#### Material profiles

Set up multilayer prints with different material profiles.

## Who’s using Voltera NOVA?

![ACI\_constrained](https://info.voltera.io/hs-fs/hubfs/ACI_constrained.png?width=469&height=281&name=ACI_constrained.png)

![Duke\_constrained](https://info.voltera.io/hs-fs/hubfs/Duke_constrained.png?width=617&height=281&name=Duke_constrained.png)

![NASA\_constrained](https://info.voltera.io/hs-fs/hubfs/NASA_constrained.png?width=443&height=341&name=NASA_constrained.png)

![Nextflex\_constrained](https://info.voltera.io/hs-fs/hubfs/Nextflex_constrained.png?width=1173&height=281&name=Nextflex_constrained.png)

![Princeton\_constrained](https://info.voltera.io/hs-fs/hubfs/Princeton_constrained.png?width=997&height=281&name=Princeton_constrained.png)

![UW\_constrained](https://info.voltera.io/hs-fs/hubfs/UW_constrained.png?width=1173&height=281&name=UW_constrained.png)

## Specifications

![Dispensing](https://info.voltera.io/hubfs/Dispensing.gif)

| **Ideal for** | - Printed electronics R&D - Functional materials research - Flexible, stretchable, conformable electronics prototyping - Microdispensing |
| --- | --- |
| **Layer capacity** | Up to 4 stack-up layers\* |
| **Material temp. control** | Up to 40°C |
| **Material compatibility** | Most screen-printable inks |
| **Minimum trace width** | 0.1 mm |
| **File formats** | - Gerber - SVG (beta) |
| \*  Designs with more than 4 stack-up layers are achievable but depend on a number of factors. For more information, contact Support at support@voltera.io. |  |

[Download Plan Datasheet](https://info.voltera.io/hubfs/_Sales%20(SALE)/Sales_Assets/NOVA%20Plan%20Feature.pdf?hsLang=en)

## What We've Printed with Plan

 Flexible LED roulette circuit

 Electroluminescent circuit

 Flexible membrane keyboard

![Flexible PCB lit up](https://info.voltera.io/hs-fs/hubfs/Flexible%20PCB%20lit%20up.jpg?width=650&height=366&name=Flexible%20PCB%20lit%20up.jpg)**Layer count**
3

**Ink**
Voltera Conductor 3 silver ink
ACI Materials FS0142 Semi-Sintering Conductive Ink
ACI Materials SI3104 Stretchable Printed Insulator

**Print time**
~30 minutes

![application\_Electroluminescent-1](https://info.voltera.io/hs-fs/hubfs/application_Electroluminescent-1.jpg?width=650&height=366&name=application_Electroluminescent-1.jpg)**Layer count**
4

**Substrate**
Paper, PET

**Ink**
Saralon electroluminescent ink suite

**Print time**
~2 hours

**![Keyboard Flexing](https://info.voltera.io/hs-fs/hubfs/Keyboard%20Flexing.jpg?width=650&height=366&name=Keyboard%20Flexing.jpg)Layer count**
3

**Substrate**
PET

**Ink**
ACI SS1109 Stretchable Silver Ink
ACI SI3104 Stretchable Printed Insulator
T4 Solder Paste Sn42Bi57.6Ag0.4

**Print time**
~20 minutes

[View More Projects](https://www.voltera.io/use-cases/white-papers)

### My research involves developing flexible and stretchable sensors for wearable electronics. With the Plan feature, I can separate different sensor elements, traces, or components to different layers and remove toolpaths that I don’t want. The ability to change the direction of tool paths has helped me the most — there’s no air pockets, and I have a very uniform trace width because I started printing in a designated safe region.

Nick Levinski, MASc student, Mechanical and Mechatronics Engineering at the University of Waterloo

### My research involves developing flexible and stretchable sensors for wearable electronics. With the Plan feature, I can separate different sensor elements, traces, or components to different layers and remove toolpaths that I don’t want. The ability to change the direction of tool paths has helped me the most — there’s no air pockets, and I have a very uniform trace width because I started printing in a designated safe region.

Nick Levinski, MASc student, Mechanical and Mechatronics Engineering at the University of Waterloo
